PRODUCTS
- Determine whether you need a Solo, Bench or Tripod pedestal.
- On your Solo pedestal, do you want to retain your existing fore/aft slider or spider/slider
-Existing fore/aft sliders need the Standard model (10xx)
-Existing 2 7/8" Spider swivels require the Spider model (30xx)
If "No" then:
May we suggest ordering the Spider model if you are ordering new hardware, with perhaps a new seat. We recommend the Garelick Spider/Slider Millenium 2000 (part # 21000) for easy installation. No orientation required on the base or spider mounting. (20xx)
- Bench models require a flat surface of 10x5 inches underneath your existing bench or leaning post to properly mount. A minimum of two (2) pedestals is required and can be ordered with either a round or flat-sided base casting. The flat-sided casting has a smaller footprint, which allows a cooler between the pedestals, and shouldn’t stick out on each side of the bench.
- Tripod bolsters require consultation with us due to the many options available.
- All models require height measurement taken from the deck surface to the bottom of the seat. Go to the Model listing below to find the corresponding height for your Post selection. Please measure before calling or ordering.
- Optimum operating weight range is 140-275 lbs of seated weight per Post. Please call us if you have applications outside this weight range.
- Dual Post is designed for longer seated weights and chairs.
- All pedestals have a shock travel of 3 ½ inches for optimal performance and safety. The shock-absorber has a stainless steel progressively rated coil-over spring and has proprietary valving for both compression and rebound strokes. That means that the initial compression is relatively soft and gets progressively stiffer. The damper valving senses the speed by which the unit compresses, so it can do its job properly. No Pogo stick here!
- Warranty click here
 | Standard Solo Post Model 10xx This patented shock-absorbing pedestal is designed to be mounted to most seats or a universal flat-bottomed seat slider for fore and aft movement. The Post swivels 360° with auto-lock forward facing feature. Proper orientation is required for installation. The round base is a standard 9 ¼” OD with a 6-hole bolt pattern. Proper operating range is between 140 -275 lbs total seated weight. Please consult the factory for heavier or other special applications. |
| Bench Post Model 20xx The two independently operating shock-absorbing pedestals are designed to function properly even when two occupants of different weights are seated. For benches over 48” or heavy duty applications, three pedestals are recommended. Posts are sold separately or in combination with a custom seat made to the desired seat length, width, color and type of material. Please consult the factory for your special applications. We recommend flat-sided bases for the outside bench posts to minimize the total footprint. Flat-sided bases measure 9-¼” fore and aft and 6” in width. 18 in (45.72 cm) 21 in (53.24 cm) 24 in (60.96 cm) 27 in (68.58 cm)
|
| Dual Solo Post Model 12xx
A Spider Solo Post Model 13xx is also available that will accept your spider/slider which fits over a 2-7/8” OD standard pedestal tube and allows 360° swiveling. |
 | Tripod Bolster Model 50xx Off-Shore pounding, racing and severe duty such as military applications call for the tripod bolster. The triangular configuration ensures maximum strength in extreme conditions. Bolsters are designed with either a sit-down or drop down seat configuration. Single or double bolster seats are available. Due to the many application variables, we can custom manufacture any model. Please consult the factory with your special application. Heights:
|
 | Gun Mount Contact us if you are interested in Gun Mounts |
This patented shock-absorbing dual pedestal system is designed to be mounted to most seats or a universal flat-bottomed seat slider for fore and aft movement. Two standard posts are utilized to accommodate larger helm chairs and greater seated weights. A custom deck plate is included which allows the pedestal system to be adapted into a standard round 8 ¼”, 6-hole bolt pattern.
16 in (40.64 cm)
